Tricot Warp Knitting Machine with 3 Guide Bars

Share to:

HTS3EL High-speed Tricot Machine

A-ZEN offers high-speed tricot machines HTS3EL and tricot warp knitting machine HKS4, which are designed for producing elastic (Lycra) warp knitted fabrics and non-elastic textiles. The EL servo drive system makes the zig-zag patterns available on the tricot warp knitting machines.

Model:
HTS3EL
Brand:
A-ZEN
Width:
218",250",290",330",372"
Gauge:
E28, E32, E36

Availability:



Inquiry PDF Download

Product Description

Overview of A-ZEN HTS3EL Tricot Warp Knitting Machine

A-ZEN offers 2-bar, 3-bar, and 4-bar high-speed tricot machines, which are designed for producing elastic and non-elastic warp-knitted textiles.

Tricot machines are equipped with compound needles, also known as bearded needles.

The sinker needles used in the tricot warp knitting machine control the fabric throughout the knitting cycle. The throats of the sinker needles hold the fabric while the tongue needles rise to form new loops.

Thanks to the EL servo drive system, the zig-zag patterns become available on the high-speed tricot warp knitting machines.

With more advanced functions applied, the tricot warp knitting machines are more durable and efficient.

The working speed of HTS3EL could reach 2,200 rpm, full bars and needle beds are made from high-strength carbon fiber material, and more flexible working widths are available: 218", 250", 290", 330", and 372".

Tricot Machine HTS3EL Fabrics Applications:

HTS3M tricot machines mainly produce automotive interior textiles, sportswear, yoga wear, upholstery velvet fabrics, mesh nets, curtains, plush toys, and many other textiles.

Tricot Bubble Fabrics

T-shirts

Home Textiles Velvet

Tricot Warp Knitting Machine HTS3EL FEATURES:

1. Stable Working Performance & Big Output

With superior component quality and precise assembly, AZEN’s wide-width, high-speed HTS3M warp knitting machine enables manufacturers to achieve up to 2 tons of home textile production per day.

2. Reliable Spare-parts Partners

(1) Needle Elements: Groz-Beckert, Saxonia (Kern-Liebers)
(2) EL Drives: Tamagawa, Yaskawa
(3) Bearings: NSK, INA, FAG
(4) Material: Reinforced Carbon Fiber
(5) Electrical: Schneider, Siemens, Omron, INVT

3. Timely Delivery

AZEN’s Tricot Machine production line ensures precise assembly and testing, achieving a monthly delivery capacity of 15 machines.

4. Overseas Service Teams Available

Türkiye, India, Germany, Egypt, Indonesia, and Iran.

PDF Documentation for HTS3M Tricot Machine

PDF Icon HKS3M Tricot Machine Catalogue

Technical Details of HKS3M Tricot Machine

Technical Specifications

1. Working Width/Gauge	218", 250", 290", 330", 372"/E24, E28, E32;
2. Working Speed	50–2,200 rpm (Depends on Yarn and Designs);
3. Bars/Knitting Elements	Individual Needle Bar with Compound Needles, Tongue Needles, and 3 Guide Bars. All Bars and Beds are Made of Carbon-fiber-reinforced Material.
4. Pattern Drive System	EL Drive;
5. Yarn Let-off Device	EBC Yarn Let-off System;
6. Fabric Take-up	Electrical Fabric Take-up System;
7. Batching Device	Electrical Batching Device;
8. Laser Stop Detector, and Air-blower Device	Equipped.
9. Heating & Fan Device	Equipped.
10. Camera Detector	Optional.

Innovations & Advantages

1. Liquid Nitrogen Cryogenic Fitting

Description: The ultra-cold assembly process using liquid nitrogen at -196°C shrinks the bearing inner ring by 0.15–0.25mm, achieving an interference fit without damaging the bearing’s internal structure.

Advantage: Prevents micro-deformation from thermal stress, maintaining ≤0.3μm preload loss over 10-year operation.

2. Thermostatic Needle Assembly

Description: Assemble needle parts in a constant temperature workshop at 25±1℃.

Advantages: Eliminates thermal expansion/contraction errors, improves operating efficiency, and reduces fabric defects.

3. 7075-T6 Aluminum Drive Components

Description: Drive parts made of 7075-T6 aluminum (572MPa UTS) with hard-coat anodization (50μm).

Advantages: Lighter yet stronger, ideal for high-speed warp knitting machines and longer machine life.

4. Full Inspection of Core Components

Description: Key components measured with a coordinate measuring machine (accuracy: 1.8 μm + L/350) to generate a 3D deviation map.

Advantages: Eliminates defective parts, reduces assembly errors, improves fit and performance.

5. Thorough In-house Testing Before Delivery

AZEN Tricot Machine Spare Parts Quality

A-ZEN Tricot machines are equipped with top brands to ensure each machine's stability and lifespan

Reinforced carbon fiber bar and beds

Full set of original German Groz-Beckert needles

Tricot Machine HTS3M Factory Production Process

1. Design & Motion Check
Innovative machine design with full running action verification.

2. Precision Component Inspection
Quality checks from oil tank production to bearing assembly.

3. Premium Parts Selection
Only high-grade components for stable performance.

4. Strict Assembly Control
Each assembly step is carefully inspected for accuracy.

5. In-House Performance Testing
Comprehensive testing before delivery to ensure reliability.

6. Secure Export Packaging
Durable and safe packing for global shipment.

production-process

Video: HTS3M Producing Tricot Fabrics

Advantages of A-ZEN Service

Original Machine Design & Custom Development

A-ZEN offers tailored machine designs and custom development solutions to meet specific client needs, ensuring optimal performance for diverse textile applications.

Original Machine Design & Custom Development

ISO-Standard Assembly and Quality Inspection

Quality Control During Assembly

Professional Packing and Shipping Team

Warp Knitting Machine Delivery

Seaworthy Package

Professional Shipping

Expert After-Sales and Global Service Network

A-ZEN provides local service in India, Türkiye, Egypt, Indonesia, Pakistan, and Iran, with plans to expand further. Our global service teams ensure timely support and maintenance.

HTS3M vs. Other Warp Knitting Machines

Model	Working Width	Speed (RPM)	Applications
HTS2M	186",218",260"	50-2300	Mosquito Net Mesh; Tulle Mesh
HTS3EL	218",290",330"	50-2200	Mercerized Velvet; Automotive Fabrics; Outerwear
HTS4EL	218",250",290",330"	50–2000	Automotive interiors, sportswear, upholstery velvet, crinkle fabrics

Sustainable Textile Production with HTS3M

The HKS3M’s energy-efficient EBC system reduces power consumption by up to 15%, and its compatibility with eco-friendly yarns supports sustainable textile manufacturing, meeting modern environmental standards.

Sustainable textile production with HKS3M

Sustainable Production

FAQs About HKS3M Tricot Machine

Q: Did you produce the tricot machines by yourself?

A: A-ZEN textile is established as a trading company to serve customers with machines, spare parts, and yarn for the international markets. But we have had our own production plant for over 10 years. We are not simply an installation factory, since we have our own professional R&D team.

Q: How are your tricot warp knitting machines different from others?

From the technical team our technical team has been in this field for more than 20 years. They know machine structures, machine parts qualities, and machine skills very well.

We have our own CNC plant. For most machine parts, we have stable suppliers, but we will still do CNC work to reduce the size difference before machine installation to improve our machine stability and make them more durable.

For after-sales service, our sales and technical teams are always online for our customers. When they need our technical support, we always provide on-time service. Meanwhile, we have a local service team in some markets.
