Vertical Curtain Warp Knitting Machine

Jacquard Curtain Machine refers to the raschel machines with piezo-jacquard system and fall plate mechanism, which is specialized to produce warp-knitted curtains. TH-5/1F is specialized to produce warp-knitted vertical curtains with jacquard patterns. Vertical curtain also be called Smart Curtain by the customers.
  • TH-5/1F

  • A-ZEN

  • 242"

  • E18



Jacquard Curtain Warp Knitting Machine refers to the raschel machines with piezo-jacquard system Smart Curtain Vertical Curtainand fall plate mechanism.The curtain produced from the Vertical Curtain Warp Knitting Machine is characterized by its various designs, obvious patterns, effective shading, and delicate surface.

As a leading jacquard raschel machine producer, A-ZEN Jacquard Curtain Machine includes TH-4/1F, TH-5/1F, and TH-7/1F three models. TH-5/1F is designed for producing vertical curtains or

smart curtains, which combine various patterns and vertical effects.

Compared to the traditional curtains, the smart curtain shows strong advantages in its vertical effect, easy to clean, and free collocation.

The creative warp-knitted curtain gains tremendous popularity once it enters the markets, and the increasing demand for it proves that this is another successful curtain textile made from warp knitting machines.

Product Description

As the most successful jacquard curtain raschel machine model, TH-5/1F has a highly reputation in its stable working performance and strong pattern-knitted function.

Working Speed 20-650rpm (depends on yarn and designs);
Working Width 242";
Gauge E18;
Bars Arrangement 1 Separate Jacquard Bar, 1 Fall Plate, and 4   Ground Bars;
Pattern Drive System Full Bars EL Drive;
Yarn Let-off Device EBC Let-off;
Fabric Take-up Device Electronical take-up device;
Beams Φ30”*21";
Main Power 11KW(242");
Jacquard Creel Chinese Type Creel, German Type Creel   (Optional).

Machine Details

smart curtain machine

raschel vertical curtain

vertical curtain machine

warp knitting machine

Machine Running Video

TH-5/1F on-site running for producing vertical warp-knitted curtain

Packaging & Shipping

warp knitting machine RJPC4F

Warp Knitting Machine Delivery

lace making machine

Seaworthty Package

Our Services

  • Local service team in Turkey, Egypt, India, Pakistan, Indonesia

  • In-time online service

  • Detailed operation manul

  • Machine in-house test before delivery

Company Information

CHANGZHOU A-ZEN TEXTILE TECHNOLOGY CO LTD. is a warp knitting machines and spare parts maunfacturer, which locates in Changzhou, China. In the past 15 years, we have already provided nearly 1,000 sets warp knitting machinery in markets, including Multi-bar Raschel machines, Jacquard Machines, Tricot Machines, Double-Needle Bars Machines and Warping Machines.

A-ZEN textile

Driven by responsible attitude, ongoing innovation, and open collaboration, A-ZEN has established a competitive warp knitting technology (WKT) portfolio of end-to-end solutions in warp knitting machinery, spare parts and technology training, and the markets including China, Turkey, India, Egypt, Indonesia, Bangladesh, Brazil, Pakistan, Syria, Iran, Kenya, Thailand, Mexico and other countires and areas.

Thanks to the sound technology and in-time after-sales service, A-ZEN has won a highly reputation from markets, and A-ZEN is committed to enabling the warp knitting future diversified industry, and building a better world.

warping knitting machine manufacture

Manufacturing Factories:

We have four workshops, two of them are warp knitting machines and warping machines workshops, another two are fabric production mill and spare parts manufacture workshop separately.

Most of our newly developed machines will be used in our fabric knitting factory for a profound test, after which, we will promote into the market.

Spare parts such as compound needle bed, tongue needle bed, needle guide bar, sinker bed, and latch needle bed are produced in our CNC machines, the bars or beds used on Chinese and German warp knitting machines.

exhibition booth Global Exhibition:

We attend professional textile machinery exhibitions worldwide, such as ITMA, ITM, ITME, and many others. During the exhibition, we not only display our newly developed technology, but also offer economical products to our customers.

It is also a good time to collect customers' feedback and new demand, so that we could make better machines for them.

Commuication and Cooperation is our theme to participate in all exhibitions.

warp knitting machine training Customer Training:

Technical support plays an extremely role in warp knitting machine services. We offer different forms of training, including professional manul book, online guide, video album, and on-site training.

So far, we have offered on-site training in more than 10 countries, and build up our own local service teams in Turkey, India, Pakistan, Indoneisa, Iran, and Egypt.

Our in-time & professional technical support gains a highly reputation in markets.


Q:  You are a trading company or a manufacturer

A:  we are a manufacturer since 2012, and we have our own trading company in 2017, the brand of which is A-ZEN, which is specialized for importing and exporting service.

Q: Do you offer local service?

A: we provide local service in India, Turkey, Egypt, Indonesia, Pakistan and Iran so far, and we will enlarge our service teams in more countries in the near future.

Q: How do you provide service if Chinese engineers can not come installation

A: Before machine delivery, we have a in-house test process, to make sure machine performance perfectly. After machine arrives, we provide in-time online guide to support our customer finish machine installation.

Q: How do you ensure your machine quality

A: Firstly, we produce and provide lots of machines to the market, and our machines' lifespan and quality ensured by different markets over the years.

Secondly, we largely use renowned and market-tested spare-part brands, to make sure the mechnical and electrical part are durable.

Besides, we have reqularl service to customers, to check our machines quality and remind customers of maintenance, so our customers could run machine always in a stable performance.
