Automotive Fabrics Warp Knitting Machine HKS3M

Automotive upholstery fabrics refer to the fabrics used as seats, the top roof lining, etc., and the fabric upholstery is produced by warp knitting or nonwoven machines. Warp knitting machine HKS3M is for producing high-performance automotive textiles.

Compared with nonwoven automotive textiles, warp-knitted fabrics are more breathable, comfortable, and healthy. The textile structure of warp-knitted fabric is more strong and solid, besides, the warp-knitted automotive upholstery could be functional, such as flame-retardant or anti-microbial.

Model:
HKS3M
Brand:
A-ZEN
Width:
186", 218", 290"
Gauge:
E36

Availability:



Inquiry

Product Description

Overview of A-ZEN HKS3M Automotive Tricot Machine

The A-ZEN HKS3M Tricot Machine (E36) is a high-speed warp knitting machine optimized for producing automotive upholstery fabrics, including seat covers, headliners, and door panels. Using polyester or nylon yarns, it delivers breathable, durable, and functional textiles with superior strength compared to nonwoven alternatives.

With a working speed of up to 2000 rpm and widths from 186" to 290", the HKS3M features Groz-Beckert compound needles, Saxonia guide needles, pattern disc drive (EL optional), EBC let-off, laser stop detection, air blower, and camera monitoring. It supports flame-retardant and antimicrobial finishes for enhanced functionality.

A-ZEN provides comprehensive support with local service in India, Türkiye, Egypt, Indonesia, Pakistan, and Iran, in-house testing, online guidance, and detailed manuals.

Automotive Upholstery

Seat Fabric

Headliner Fabric

warp-knitting-machine-for-automotive-textile

HKS3M Machine

PDF Documentation for HKS3M Tricot Machine

PDF Icon HKS3M Automotive Tricot Machine Catalogue

Technical Details of HKS3M Tricot Machine

Technical Specifications

1	Working Width/Gauge	186", 218", 245", 290" / E28, E32, E36
2	Working Speed	50–1900 rpm (up to 2000 rpm)
3	Bars/Knitting Elements	Individual Needle Bar (Compound/Tongue Needles), 3 Guide Bars, Carbon-Fiber-Reinforced Beds
4	Pattern Drive System	Pattern Discs (EL Drive Optional)
5	Yarn Let-off Device	EBC Yarn Let-off System
6	Fabric Take-up	Electronic Fabric Take-up System
7	Batching Device	Electronic Batching Device
8	Laser Stop & Online Service	Equipped
9	Air Blower Device	Equipped

Key Features & Components

High-Speed Production: Up to 2000 rpm for maximum efficiency.
Premium Components: Groz-Beckert & Saxonia needles, NSK/INA/FAG bearings, Mitsubishi/Nidec/Yaskawa EL drives, Schneider/Siemens/Omron/INVT electronics, Bobotex take-up belts.
Functional Fabrics: Supports flame-retardant and antimicrobial treatments.
Global Service: Local teams in Türkiye, India, Egypt, Indonesia, Pakistan, Iran.

Automotive Seat Fabric

Headliner Fabric

HKS3M in Production

Automotive Textile Output

Video: HKS3M Tricot Machine in Operation

Watch the HKS3M producing high-performance automotive upholstery fabrics at full speed.

Advantages of A-ZEN Service

Original Machine Design & Custom Development

A-ZEN offers tailored machine designs and custom development solutions to meet specific client needs, ensuring optimal performance for diverse textile applications.

Original Machine Design & Custom Development

ISO-Standard Assembly and Quality Inspection

Quality Control During Assembly

Professional Packing and Shipping Team

Warp Knitting Machine Delivery

Seaworthy Package

Professional Shipping

Expert After-Sales and Global Service Network

A-ZEN provides local service in India, Türkiye, Egypt, Indonesia, Pakistan, and Iran, with plans to expand further. Our global service teams ensure timely support and maintenance.

FAQs About HKS3M Automotive Tricot Machine

How is the quality of the HKS3M Tricot Machine?

The HKS3M features premium components, rigorous in-house testing, and over 15 years of market validation. Customers consistently place repeat orders due to its reliability and performance.
