The A-ZEN RD6-EL is engineered to produce high-quality 3D air-mesh spacer fabrics, also known as three-dimensional mesh textiles, widely used in sports shoe uppers, automotive seats, mattress textiles, and other applications. These fabrics offer thicknesses from 1mm to 50mm, ensuring versatility for various industries.
Introduced in 2014, the A-ZEN RD6-EL double needle bar raschel machine has undergone continuous improvements in its warp knitting mechanical structure and electronic components. With market-tested technology and durable parts, it is a top choice among A-ZEN’s warp knitting machines.
Featuring 6 ground bars, a knock-over comb bar distance of 2-12mm, and available working widths of 138" and 210", the RD6-EL delivers exceptional performance. A-ZEN also offers other models, including RD7, RDJ5/1, RDJ4/2, and AZ2885.
3D Spacer Fabric
Air-Mesh Textile
Mattress Textile
| 1 | Working Width | 138", 210" |
| 2 | Machine Gauge | E18, E22, E24, E28 |
| 3 | Working Speed | 50-750 RPM (Depends on Yarn and Designs) |
| 4 | Knock-over Comb Bar Distance | 2-12mm |
| 5 | Bars/Knitting Elements | 2 needle bars with latch needle units (individual needle and needle block optional), 2 knock-over comb bars, 6 ground bars |
| 6 | Pattern Drive System | Pattern Discs Drive or EL Drive (Optional) |
| 7 | Yarn Let-off Device | EBC Yarn Let-off System |
| 8 | Fabric Take-up | Electronic Fabric Take-up System |
| 9 | Batching Device | Electronic Batching Device |
| 10 | Laser Stop Detector and Online Service Program | Optional |
| 11 | Air Blower Device | Optional |
| 12 | In-house Test | Optional |
Machine Dimensions (Side View)
Machine Dimensions (Top View)
Ensures consistent output for 3D mesh textiles with reliable operation.
Sourced from top suppliers: Needle Elements (Groz-Beckert, Saxonia), EL Drives (Mitsubishi, Nidec, Yaskawa), Bearings (NSK, INA, FAG), Needle Beds and Bars (Magnalium Material), Electrical Elements (Schneider, Siemens, Omron, INVT), Take-up Belt (Bobotex).
The EBC yarn let-off system reduces energy consumption by up to 15%.
Mitsubishi EL drives ensure accurate 3D mesh patterns for diverse applications.
Magnalium needle beds and NSK bearings enhance machine longevity.
Individual Latch Needles
Block Latch Needles
Knock-over Comb Bar
Guide Ground Bar
Air-Mesh Fabric
Customer's Production Factory
Changzhou A-ZEN Warp Knitting
Overseas Machine Delivery
The RD6-EL produces lightweight, breathable air-mesh fabrics, ideal for high-performance sports shoes, offering flexibility in design and superior comfort.
Our 3D spacer fabrics provide excellent durability and ventilation, enhancing comfort for automotive upholstery while meeting eco-friendly standards.
With thicknesses up to 50mm, RD6-EL fabrics ensure optimal air circulation and pressure resistance for premium mattress production.
Watch the RD6-EL in action producing air-mesh sports shoe textiles in Türkiye, 2021.
A-ZEN offers tailored machine designs and custom development solutions to meet specific client needs, ensuring optimal performance for diverse textile applications.
Quality Control During Assembly
Final Quality Assurance
Warp Knitting Machine Delivery
Seaworthy Package
A-ZEN provides local service in India, Türkiye, Egypt, Indonesia, Pakistan, and Iran, with plans to expand further. Our global service teams ensure timely support and maintenance.
| Model | Working Width | Speed (RPM) | Applications |
|---|---|---|---|
| RD6-EL | 138", 210" | 600-750 | 3D spacer fabrics, sports shoes, automotive seats |
| RD7 | 138", 200" | 500-700 | General warp knitted fabrics |
The RD6-EL’s energy-efficient design reduces power consumption by up to 15%, and its compatibility with eco-friendly yarns supports sustainable textile manufacturing, meeting modern environmental standards.
Sustainable Production
The RD6-EL double needle bar warp knitting machine operates at a stable speed of 600-750 RPM, depending on yarn and design specifications.
Supported by an experienced installation and R&D team
Uses branded electrical and imported mechanical parts for reliability
Each machine is rigorously tested before delivery
Continuous improvements based on customer feedback ensure stable, high-quality performance
The RD6-EL supports a wide range of yarns, including polyester, nylon, and blended fibers, ensuring versatility for 3D spacer fabric production.
Regular maintenance includes cleaning needle beds, checking EL drives, and following our detailed operation manual. A-ZEN’s service teams offer ongoing support.
We provide local service in India, Türkiye, Egypt, Indonesia, Pakistan, and Iran, with plans to expand further. Additionally, we offer detailed operation manuals and online technical support for efficient machine adjustments.
